Durston Powered Rolling Mill TUI 130 Double
Code: 18558Product detailed description
The rolls themselves provide a dedicated flat rolling side, with a width of 130mm and a maximum roll thickness of 6mm, and a dedicated square groove wire rolling side, providing 19 grooves from 10mm to 1mm to create a perfect finish every time. The 1.1KW 110-volt motor offers consistent power through the lifetime of the mill. Digitally controlled variable speeds from 5 to 20 RPM means you have complete control over each roll and the side extensions provide for half rounds of 8, 6, 4, 3, 2, 1.5 mm for additional versatility.
Additional parameters
| Category: | Rolling Mills |
|---|---|
| Weight: | 179 kg |
| EAN: | 9318558 |
| Hmotnost: | 160 kg |
| Rozměry (ŠxHxV): | 840x540x540 mm |
| Externí rolny: | 8, 6, 3 mm a 4, 3, 2, 1,5 mm |
| Max. síla drátu: | 10 mm |
| Max. tloušťka plechu: | 6 mm |
| Počet drážek na drát: | 19 (1 - 10 mm) |
| Průměr rolny: | 65 mm |
| Šířka ploché části rolny: | 130 mm |
| Šířka rolny: | 130 mm |
